Specifications
Speaker type | - Floor standing sculptured tower with a dynamic 2 1/2 way, 3 speaker system and bass reflex loading |
Continuous power rating | - 150 Wrms system power |
Frequency response | - 32 Hz 20kHz +/- 3db |
Efficiency | - 97 db/w/m |
Recommended amplifiers | - 3.5 300 Wrms into 8 ohms |
Crossover frequency | -
2,200 Hz acoustic - 80 Hz acoustic low pass filtering of rear woofer |
Impedance | - 6 ohms nominal with minimal impedance variation |
Dimensions | -
16 W x 18 D x 45 Ό H - 41cm W x 46cm D x 115cm H |
Net weight | - approx 150lbs, 68kgs |
Cabinet | -
Front wall constructed with a proprietary 1 ½ / 37mm laminate of
MDF, plastic and cotton, that has a broadband attenuation of 46 db - Select panels are damped with a lead, rubberized bitumen laminate - Extensive internal bracing used throughout |
Crossover | - Audiophile, premium grade components and wiring tuned for a smooth frequency response with minimal off axis variation and low system distortions |
Woofer | -
Two 10 / 25cm, 200 Wrms drivers each with a cast basket, rough
molded heavy paper cone, doped and pleated cloth surround, massive
focused 90oz. magnet and 3 / 75mm voice coil - Linear Xmax of +/- 4.5mm |
Tweeter | Precision machined aluminum faceplate with phase plug, aluminum dome, braided lead wires and a powerful magnet system without liquid cooling for maximum transient performance and efficiency |
